- 50 -
3 Wiring
3
Note
Improperuseofbatterymayresultinbatteryleakagewhichwillcorrodethecomponentsor
causethebatterytoexplode.Observethefollowingprecautionsduringuse:
1. Placethebatteryinthecorrect+/–polarity;
2. If you place a battery that has been used for a long time or a dead battery in the device,
batteryleakagemayoccur,corrodingsurroundingcomponents;asthebatteryisconductive
itmaycauseashortcircuit.Replacethebatteryperiodically(recommendedperiod:Every2
years).
3. NEVER decompose the battery, so as to prevent personal injury by spraying of electrolyte.
4. NEVERputthebatteryinare.Failuretocomplymayresultinanexplosion.
5. Prevent a battery short circuit, and never strip the battery tube. Do not connect metal to
theelectrodesofthebattery.Otherwise,alargecurrentisproduced,weakeningthebattery
power which could result in an explosion due to severe heating.
6. This battery is not chargeable.
7. Reminder:Disposethebatteryaccordingtolocalregulations.
Battery selection:
Select an appropriate battery according to the following table.
Table 3-12 Battery description for the absolute encoder
Battery
Specication
Item and Unit
Rated Value
Condition
Minimum
Value
Typical
Value
Maximum
Value
Output:3.6V,
2,500 mAh
Recommended
manufacturer and
model:Shenzhen
Jieshun Science
and Technology
Industry Co., Ltd.,
LS14500
External battery voltage (V) 3.2 3.6 5 In standby mode*
2
Circuit fault voltage (V) 2.6 In standby mode
Battery alarm voltage (V) 2.85 3 3.15
Current consumed by circuit
(uA)
2 During normal operation*
1
10 In standby mode, axis static
80 In standby mode, axis rotation
Batteryworkingambient
temperature (
℃
)
0 40
The same as that required by
the motor
Battery storage ambient
temperature (
℃
)
–20 60
The preceding data is measured in the ambient temperature of 20℃.
Note
*1:Normaloperationmeansthattheabsoluteencodercancount,receiveandsenddata
generated from single rotation and multiple rotations. After the absolute encoder is correctly
connected,itwillworknormallyandreceiveandsenddataafterashortdelay(about5
seconds) when the servo drive is powered on. Switching the absolute encoder from standby
mode to normal operation mode (power is on) requires the motor to rotate at a speed less than
10 RPM, otherwise the drive may report 740 error. In this case, power on the servo drive again.
*2:Standbymodemeansthattheservodriveisnotpoweredonandtheabsoluteencodercan
perform multi-rotation counting by utilizing external battery power. In this mode, the absolute
encoder stops receiving and sending data.
