Chapter: Installation
46 M10-17547-EN
Rear panel connections detail
Figure 9. Rear panel connections detail
Legend for Figure 9
Label Component More detail
6 Pneumatic grips - grip 1 connector
(typically upper grip)
7 Pneumatic grips - grip 2 connector
(typically lower grip)
8 Pneumatic grips - air inlet connector 120 psi (8.3 bar) maximum
