Integra DTM-5.9 User Manual

45
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
Rated Output Power (FTC)
All channels: 100 watts minimum continuous power
per channel, 8 ohm loads, 2 channels
driven from 20 Hz to 20 kHz, with a
maximum total harmonic distortion of
0.08 %
Dynamic Power
North American: 230 W + 230 W (4 Ω)
170 W + 170 W (6 Ω)
145 W + 145 W (8 Ω)
THD (Total Harmonic
Distortion) 0.08 % (Power Rated)/ 0.08 % (1 kHz,
1 W)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and
Impedance 150 mV/ 50 kΩ (LINE)
2.5 mV/ 50 kΩ (PHONO MM)
Output Level and
Impedance 150 mV/ 2.2 kΩ (REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB–3 dB (CD)
Tone Control ±10 dB, 100 Hz (Bass)
±10 dB, 10 kHz (Treble)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Speaker Impedance 4 Ω–16 Ω
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75Ω (Composite)
Tuning Frequency
Range 87.5 MHz– 107.9 MHz
Tuning Frequency
Range 530 kHz–1710 kHz
Preset Channel 40
Power Supply AC 120 V, 60 Hz
Power Consumption 2.8 A
Standby Power
Consumption 0.2 W
Dimensions
(W
× H × D) 435 × 149 × 335 mm
17-1/8" × 5-7/8" × 13-3/16"
Weight 8.8 kg
19.4 lbs.
Composite DVD, VCR/DVR, CBL/SAT, GAME/TV
Composite MONITOR OUT, VCR/DVR, ZONE2
Analog Inputs PHONO, CD, TAPE, GAME/TV,
CBL/SAT, DVD, VCR/DVR
Analog Outputs TAPE, VCR/DVR
Speaker Outputs Speakers A
Speakers B
Phones 1
Pre Outputs 2 (L/R)
Subwoofer Pre Outputs 1
Zone 2 Pre Output 2 (L/R)
RS232 1
IR Input/Output 2/1
12V Trigger Out 3
