Appendix
General Specications
Amplier Section North American models Middle East, Australian and Asian models
Rated Output Power *
With 8 ohm loads, both channels driven, from
20 Hz-20 kHz; rated 110 watts per channel
minimum RMS power, with no more than 0.08%
total harmonic distortion from 250 milliwatts to rated
output.
2 ch × 140 W at 6 ohms, 1 kHz, 2 ch driven of 1% THD
210 W at 6 ohms, 1 kHz, 2 ch driven of 10% THD
2 ch × 170 W at 6 ohms, 1 kHz, 2 ch driven of 10% THD
(JEITA)
0.08% (20 Hz - 20,000 Hz, Rated output power)
Input Sensitivity and Impedance
Rated RCA Output Level and Impedance
Phono Maximum Input Signal Voltage 70 mV (MM 1 kHz 0.5%), 7 mV (MC 1 kHz 0.5%)
Frequency Response
Tone Control Characteristics ±10 dB, 100 Hz (Bass), ±10 dB, 10 kHz (Treble)
Signal to Noise Ratio
106 dB (IHF-A, LINE IN, SP OUT),
76 dB (IHF-A, PHONO MM 5mV IN, SP OUT),
60 dB (IHF-A, PHONO MC 0.5mV IN, SP OUT)
Supported impedance of Speakers
Headphone Rated Output
Supported impedance of Headphones
Headphones Frequency Response 5 Hz - 100 kHz (Direct)
*Typical usage is 1/8th power (Sine wave) on 2 ch channels into the rated load. Full power is expected to be used in extreme case for a while.
