Integra DTM-7.4 - Connecting Antennas (North American Models Only)

29
Connections
Connecting Antennas (North American models only)
SPEAKERS
R L
A
L
R
B
FM
75Ω
PC
R
L
PRE OUT
ZONE 2 MAIN
SUB-
WOOFER
AM
R
L
PRE/LINE OUT
RS232
OUT
IN
A
B
TUNER
A B
Connect the antenna to this unit, and set up the antenna at the best position for
listening while receiving radio signals.
• Attach the indoor FM antenna to the wall using push pins or adhesive tape.
a AM loop antenna, b Indoor FM antenna
