LFX12V Specific Guidelines 1.43
46 Design Guide
11 LFX12V Specific Guidelines 1.43
For Low Profile Form Factor with 12-volt connector power supplies.
All Form Factors Revision Summary:
PSU DG CFX12V LFX12V ATX12V SFX12V TFX12V Flex ATX
1.31 1.5 1.3 2.4 3.3 2.4 1.1
1.4 1.6 1.4 2.5 3.4 2.5 1.2
1.42 1.62 1.42 2.52 3.42 2.52 1.22
1.43 1.63 1.43 2.53 3.43 2.53 1.23
11.1 Physical Dimensions - Required
The power supply shall be enclosed and meet the physical outline shown in Figure
11-1, applicable. Mechanical details are shown in Figure 11-2. Details on the power
supply slot feature are shown in Figure 11-3. The recommended chassis slot feature
details are shown in Figure 11-4.
Figure 11-1: LFX 12V Mechanical Outline
