PCI Express* Add-in Card Considerations
613768 25
Power connectors. Each Auxiliary Power Connector must have voltage pins that belong
to the same +12V power converter if multiple voltage rails exist from the PSU.
Table 3-5: Auxiliary Power Connectors Power Supply Rail Requirements - +12V Only
+12V Power Rail
Characteristic
2x3 Connector 2x4 Connector
12VHPWR
Connector
Sustained Power
2, 4, 5
75 Watts 150 Watts 600
+ 12 V
Voltage Range
+5% / -8% +5% / -8% +5% / -8%
Current
3, 4, 5
(Max RMS)
6.75 Amps 13.5 Amps 55 Amps
1
NOTES:
The maximum current slew rate for the 12VHPWR connector interface shall be no more
than 5.0 A/µs.
Maximum sustained power is an average power in any continuous 1 second interval
Maximum of root-mean-square (RMS) of current in any continuous 1 second interval
The main reference limit is the maximum allowed sustained power per connector and
Add-in Card type. Add-in Card and System must concurrently comply with all power
and voltage and current requirements in this table for the applicable connector and
other requirements in this specification for the Add-in Card type.
Maximum instantaneous and other excursions exceeding these limits are defined in
Section
3.1 of this document.
3.3 PCIe* Add-in-Card Auxiliary Power Connectors
Sideband Signals
The new 12VHPWR connector has 4 sideband signals defined that communicate
between the Power Supply and the PCIe* Card. Two of these sideband signals are
required with the connector and two of them are optional from the Power Supply. The
four sideband signals are:
SENSE0
SENSE1
CARD_PWR_STABLE
CARD_CBL_PRES#
For the most up to date and detailed description, refer to Section 5.3
Optional
Sideband Signal in the PCI Express* Card Electromechanical Specification, Rev
5.0. That document is available from
www.pcisig.com.
3.3.1 Sense1 / Sense0 (Required)
These two sideband signals provide important information from the PSU to the Add-in
Card and are therefore required from the power supply. These signals allow the PSU to
tell the Add-in Card how much power the Add-in Card can use during both Initial
Power Up and Maximum Permitted Power. In the PCI CEM Gen 5 spec these levels are
called “Connector Initial Permitted Power” and “Connector Maximum Permitted Power”
because they refer to the power limits that can be consumed thorough the Auxiliary
