4.5.5. NAND Flash Interface Design Guidelines
GUIDELINE: Ensure that the selected NAND flash device is an 8-bit ONFI 1.0
(or later) compliant device.
The NAND flash controller in the HPS requires:
• The external flash device to be 8-bit ONFI 1.0 compliant
• Single-level cell (SLC) or multi-level cell (MLC)
• Page size: 512 bytes, 2 KB, 4 KB or 8 KB
• Pages per block: 32, 64, 128, 256, 384 or 512
• Error correction code (ECC) sector size can be programmed to 512 bytes (for 4-,
8- or 16-bit correction) or 1024 bytes (24-bit correction)
You cannot export the NAND interface to FPGA.
Note: Refer to Supported Flash Devices for Cyclone V and Arria V SoC for a list of supported
NAND devices.
4.5.6. UART Interface Design Guidelines
GUIDELINE: Properly connect flow control signals when routing the UART
signals through the FPGA fabric.
When routing UART signals through the FPGA, the flow control signals are available. If
flow control is not being used, connect the FPGA signals as shown in the following
table.
Table 9. UART Connections to Disable Flow Control
Signal Direction Connection
CTS
Input Low
DSR
Input High
DCD
Input High
RI
Input High
DTR
Output No-connect
RTS
Output No-connect
OUT1_N
Output No-connect
OUT2_N
Output No-connect
4. Board Design Guidelines for SoC FPGAs
AN-796 | 2018.06.18
AN 796: Cyclone V and Arria V SoC Device Design Guidelines
46

Intel Cyclone V Specifications

General

FPGA Family	Cyclone V
Logic Elements	25K to 301K
Transceivers	Up to 12
Processor	Dual-core ARM Cortex-A9
Process Technology	28 nm
Embedded Memory	M10K blocks
Operating Temperature	0°C to +85°C (Commercial), -40°C to +100°C (Industrial), -40°C to +125°C (Automotive)
Power Consumption	Varies by configuration and usage
Maximum User I/O	Up to 524
