Intel E810 VDA4T Series - Page 44

Intel
®
Ethernet Network Adapter E810-XXVDA4T
User Guide
44 646265-004
Or:
#dmesg
[101056.462309] ice 0000:18:00.0: SMA1 RX + U.FL1 TX
[101056.462317] ice 0000:18:00.0: UFL2 RX
[101090.668497] driver cannot use function 1 on pin 0
4. Run ts2phc:
Running on Port 0:
# ethtool --set-priv-flags $ETH extts_filter on
# ./ts2phc -f configs/ts2phc-generic.cfg -s generic -m
Note: See Section 5.8, “Example ts2phc Configuration File”.
Note: You might want filter the 1PPS timestamps till the DPLL locked. See Section 4.13.
5. Run ptp4l:
Running on Port 0 (1,2 and 3 as well if required):
# ./ptp4l -i $ETH -m
6. Run synce4l (optional):
#./synce4l -f configs/synce4l.cfg -m
Note: Refer to Section 5.10, “Example synce4l Configuration File for BC”.
Note: For GM mode, ensure that input_mode = external is used in the config file.
