646265-004 61
Intel
®
Ethernet Network Adapter E810-XXVDA4T
User Guide
[unicast_master_table]
table_id 1
logQueryInterval 2
UDPv4 192.168.2.1
[enp1s0f3]
serverOnly 0
unicast_master_table 1
5.10 Example synce4l Configuration File for BC
Note: For GM mode, ensure that input_mode = external is used in the config file.
# Global section is for debuging mostly
[global]
#
# Runtime options
#
logging_level 7
use_syslog 0
Verbose 1
message_tag [synce4l]
#
# Device section
# Per-device configuration
#
# User defined name of a one logical device configured for SyncE in the system.
# All the ports configured after this section will be a part of this device
# (until next device section).
[<synce1>]
#
# Mode for synce4l operation.
# There are two currently supported modes:
# - line
# - external
#
# Input mode "line" mean the inputs recovered from the PHY's.
# The ports configured (in the port-sections [<dev_name>], under the device
# section) will be monitored for the QL (Quality Level).
# QL is sent by the peer connected to the port and represents the Holdover
# performance of the peer.
# The best QL is selected and frequency recovered on that port shall be used
# to feed its frequency to all the other ports.
#
# The "external" input mode are either 1PPS from built-in GPS module or 1PPS
# from the on-board SMA connectors. Device must be pre-confiured to use this
# setting. # Before running the application, one of the external inputs shall be
# selected. This is done through the interface supplied by the adpater vendor.
#
# In this mode synce4l application is only responsible for sending
# the QL to the peers on all configured ports.
# The QL value that is sent equals configured "external_input_QL"
# (and "external_input_ext_QL" in case of "extended_tlv=1").
#
