Intel
®
Ethernet Network Adapter E810-XXVDA4T
User Guide
48 646265-004
Note: If U.FL1 if set to Tx then SMA1 is also set to Rx and cannot be changed. Make sure no
1PPS input is connected to SMA1 if using U.FL1 as Tx.
4. Verify if the outputs were set correctly:
#dmesg
[ 827.397307] ice 0000:18:00.0: SMA1 TX
[ 827.397315] ice 0000:18:00.0: SMA2 + U.FL2 disabled
[ 837.852127] ice 0000:18:00.0: <DPLL1> state changed to: unlocked, pin CVL-SDP20
[1243.385109] ice 0000:18:00.0: <DPLL1> state changed to: locked, pin CVL-SDP20
Or:
#dmesg
[ 7827.397307] ice 0000:18:00.0: SMA1 RX + U.FL1 TX
[ 7827.397315] ice 0000:18:00.0: SMA2 + U.FL2 disabled
[ 7837.852127] ice 0000:18:00.0: <DPLL1> state changed to: unlocked, pin CVL-SDP22
[10243.385109] ice 0000:18:00.0: <DPLL1> state changed to: locked, pin CVL-SDP22
#dmesg
[ 827.397307] ice 0000:18:00.0: SMA1 + U.FL1 disabled
[ 827.397315] ice 0000:18:00.0: SMA2 TX
[ 837.852127] ice 0000:18:00.0: <DPLL1> state changed to: unlocked, pin CVL-SDP20
[1243.385109] ice 0000:18:00.0: <DPLL1> state changed to: locked, pin CVL-SDP20
Note: The first two lines of each dmesg changes depending on what outputs are enabled for
visibility.
5. Run ptp4l:
./ptp4l -i $ETH -m -s
