Page #8 background image
Intel
®
Ethernet Network Adapter E810-XXVDA4T
User Guide
8 646265-004
Table 2 provides additional information on the E810-XXVDA4T:
Table 2. E810-XXVDA4T Product Information
Product Description 1588 PTP/SyncE/GNSS 10/25GbE SFP28 PCIe adapter
Product Codes
E810-XXVDA4TG1 (no GNSS)
E810-XXV-DA4TGG1 (with GNSS)
Host Interface PCIe 3.0x16 or PCIe 4.0x8/x16 (x16 connector)
Form Factor Full-height, half-length PCIe card
Front Panel Connectors 4x SFP28, 2x SMA (1PPS/10 MHz)
1
, 1x SMB (GNSS antenna)
2
1. Refer to Section 2.3 for 1PPS and 10 MHz signaling requirements.
2. Refer to Table 3 for GNSS antenna characteristics.
Internal Connectors 1x U.FL input + 1x U.FL output (1PPS/10 MHz); GNSS mezzanine
Optional GNSS SKU Supports GPS, Galileo, GLONASS, BeiDou, QZSS
Synchronous Ethernet ITU-T G.8261, G.8262, G.8262.1, and G.8264 (ESMC) support
Oscillator 1 ppb vs. temperature, 4 hours holdover (±1.5 µs under ±5 °C T)
Power 23 W typical, 34 W max power consumption (with Class 3 optics at 25G maximum traffic)
Operating Temperature 0-61 °C with required airflow (passive heat sink); 65 °C target
EMI FCC Class A
Manageability NC-SI over MCTP (over PCIe/SMBus); EFI based iSCSI boot; EFI/legacy PXE boot support
