Intel S1200BTS User Manual

Connector/Header Locations and Pin-outs Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
96
7.5 I/O Connectors
7.5.1 VGA Connector
The following table details the pin-out definition of the VGA connector (J7A1 on S1200BTL and
J6A1 on S1200BTS):
Table 28. VGA Connector Pin-out
Pin
Signal Name
Description
1
V_IO_R_CONN
Red (analog color signal R)
2
V_IO_G_CONN
Green (analog color signal G)
3
V_IO_B_CONN
Blue (analog color signal B)
4
TP_VID_CONN_B4
No connection
5
GND
Ground
6
GND
Ground
7
GND
Ground
8
GND
Ground
9
TP_VID_CONN_B9
No connection
10
GND
Ground
11
TP_VID_CONN_B11
No connection
12
V_IO_DDCDAT
DDCDAT
13
V_IO_HSYNC_CONN
HSYNC (horizontal sync)
14
V_IO_VSYNC_CONN
VSYNC (vertical sync)
15
V_IO_DDCCLK
DDCCLK
7.5.2 Rear NIC and USB connector
The server board provides two stacked RJ-45/2xUSB connectors side-by-side on the back edge
of the board. The pin-out for NIC connectors is identical and defined in the following table:
Table 29. RJ-45 10/100/1000 NIC Connector Pin-out
Pin
Signal Name
Pin
Signal Name
1
P5V_USB_PWR75
2
USB_PCH_11_FB_DN
3
USB_PCH_11_FB_DP
4
GND
5
P5V_USB_PWR75
6
USB_PCH_10_FB_DN
7
USB_PCH_10_FB_DP
8
GND
9
P1V9_LAN2_R
10
NIC2_MDIP<0>
11
NIC2_MDIN<0>
12
NIC2_MDIP<1>
13
NIC2_MDIN<1>
14
NIC2_MDIP<2>
15
NIC2_MDIN<2>
16
NIC2_MDIP<3>
17
NIC2_MDIN<3>
18
GND
19
LED_NIC2_1
20
P3V3_AUX
21
LED_NIC2_LINK100_R_0
22
LED_NIC2_LINK1000_2

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
