Design and Environmental Specifications Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
112
suggested thermal and current design values for anticipating future processor needs. The
following table provides maximum values for Icc, TDP power and T
CASE
for the Intel
®
Xeon
®
SandyBridge Series processor.
Table 46. Intel
®
Xeon
®
Processor TDP Guidelines
TDP Power
Maximum T
CASE
Icc Maximum
95 W
67.0º C
150 A
10.3 Power Supply Output Requirements
This section is for reference purposes only. The intent is to provide guidance to system
designers to determine a power supply for use with this server board. This section specifies the
power supply requirements Intel
®
used to develop a power supply for the Intel
®
Server System
R1304BTLSHBN.
The following tables define two power and current ratings for this 350-W power supply. The
combined output power of all outputs should not exceed the rated output power. The power
supply must meet both static and dynamic voltage regulation requirements for the minimum
loading conditions.
Table 47. 350-W Load Ratings
Voltage
Minimum Continuous
Maximum Continuous
Peak
+3.3 V
0.2A
14 A
+5 V
1.0 A
18A
+12 V
1.5A
24 A
28A
-12 V
0A
0.3A
+5 VSB
0.1 A
2.0 A
2.5 A
Notes:
1. Maximum continuous total DC output power should not exceed 350 W.
2. Peak total DC output power should not exceed 400 W.
3. Peak power and peak current loading should be supported for a minimum of 12 seconds.
4. Combined 3.3 V/5 V power should not exceed 100 W.

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
