Functional Architecture Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
3.6.5 Keyboard and Mouse Support
The server board does not support PS/2 interface keyboards and mouse. However, the system
BIOS recognizes USB specification-compliant keyboard and mouse.
3.6.6 Wake-up Control
The super I/O contains functionality that allows various events to power on and power off
the system.
3.7 Video Support
3.7.1 Intel
®
Server Board S1200BTL
The server board includes on-board Server Engine* LLC Pilot III* Controller with 128 MB DDR3
memory in which 8MB is usable/accessible memory for iBMC video/graphic display functions.
The graphic controller internally has access to larger memory for the internal operations. The
32MB memory reported by display driver is the attached memory. Attached memory can be
32MB or greater but only 8MB is accessible for display functions.
3.7.1.1 Video Modes
The integrated video controller supports all standard IBM VGA modes. The following table
shows the 2D modes supported for both CRT and LCD.
Table 9. Video Modes
60, 70, 72, 75,
85, 90, 100, 200
60, 70, 72, 75,
85, 90, 100,120,
160
60, 70, 72, 75,
85, 90, 100
43, 47, 60, 70,
75, 80, 85
3.7.1.2 Dual Video
The BIOS supports both single-video and dual-video modes. The dual-video mode is disabled
by default.
In the single mode (dual monitor video = disabled), the on-board video controller is
disabled when an add-in video card is detected.
In single mode, the onboard video controller is disabled when an add-in video card
is detected.
