Intel® Server Board S1200BT TPS Functional Architecture
Revision 1.0
Intel order number G13326-003
29
 In dual mode, the onboard video controller is enabled and is the primary video device.
The external video card is allocated resources and is considered the secondary
video device.
 When KVM is enabled in iBMC FW, dual video is enabled.
Table 10. Dual Video Modes
Onboard Video
Enabled
Disabled
Onboard video controller.
Warning: System video is completely disabled if
this option is disabled and an add-in video
adapter is not installed.
Dual Monitor Video
Enabled
Disabled
If enabled, both the onboard video controller
and an add-in video adapter are enabled for
system video. The onboard video controller
becomes the primary video device.
3.7.2 Video for Intel
®
Server Board S1200BTS
SM712 is a video chip from Silicon Motion, Inc (SMI). It is one in SMI‘s LynxEM family. It is PCI
2.1 compliant with the standard PCI 33MHz & 66 MHz PCI Master/Slave interface.
 33 MHz & 66 MHz PCI Master/Slave interface
 PCI 2.1 compliant
 Memory control is provided for the 4MB internal memory
 Support 640x480, 800x600, 1024x768 resolution and up to 85Hz.
 Dual Video mode is supported.
3.8 Network Interface Controller (NIC)
The Intel
®
Server Board S1200BT supports two network interfaces, One is provided from the
onboard Intel
®
82574L GbE PCI Express network controller; the other is the onboard Intel
®
82579 Gigabit Network controller.
3.8.1 Gigabit Ethernet Controller 82574L
The 82574 family (82574L and 82574IT) are single, compact, low-power components that offer
a fully-integrated Gigabit Ethernet Media Access Control (MAC) and Physical Layer (PHY) port.
The 82574 uses the PCI Express* architecture and provides a single-port implementation in a
relatively small area so it can be used for server and client configurations as a LAN on
Motherboard (LOM) design.
External interfaces provided on the 82574:
 PCIe Rev. 2.0 (2.5 GHz) x1
 MDI (Copper) standard IEEE 802.3 Ethernet interface for 1000BASE-T, 100BASETX,
and 10BASE-T applications (802.3, 802.3u, and 802.3ab)
 NC-SI or SMBus connection to a Manageability Controller (MC)
 EEE 1149.1 JTAG (note that BSDL testing is NOT supported)
3.8.2 Gigabit Ethernet PHY 82579
The 82579 is a single port Gigabit Ethernet Physical Layer Transceiver (PHY). It connects to
the Intel
®
C200 series Chipset‘s integrated Media Access Controller (MAC) through a dedicated
interconnect. The 82579 supports operation at 1000/100/10 Mb/s data rates. The PHY circuitry

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
