Intel® Server Board S1200BT TPS Connector/Header Locations and Pin-outs
Revision 1.0
Intel order number G13326-003
99
7.5.6 USB Connector
There are four external USB ports on two NIC/USB combinations. Section 5.5.2 details the pin-
out of the connector.
Two 2x5 connector on the server board (J1D1, J1E1) provides an option to support an
additional USB port, each connector supporting two USB ports. The following table defines the
pin-out of the connector.
Table 36. Internal USB Connector Pin-out ( J1E1, J1D1)
Pin
Signal Name
Description
1
USB2_VBUS4
USB power (port 4)
2
USB2_VBUS5
USB power (port 5)
3
USB_ICH_P4N_CONN
USB port 4 negative signal
4
USB_ICH_P5N_CONN
USB port 5 negative signal
5
USB_ICH_P4P_CONN
USB port 4 positive signal
6
USB_ICH_P5P_CONN
USB port 5 positive signal
7
Ground
8
Ground
9
Key
No pin
10
TP_USB_ICH_NC
Test point
One 2x5 connectors on the server board provides an option to support Smart module. The
following table defines the pin-out of the connector:
Table 37. Pin-out of Internal USB Connector for low-profile Smart module (J3F2)
Pin
Signal Name
Description
1
+5V
USB power
2
NC
N/A
3
USB Data -
USB port ## negative signal
4
NC
N/A
5
USB Data +
USB port ## positive signal
6
NC
N/A
7
Ground
N/A
8
NC
N/A
9
Key
No pin
10
LED#
Activity LED

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
