Intel S1200BTS User Manual

Appendix C: POST Code Diagnostic LED Decoder Intel® Server Board S1200BT TPS
Revision 1.0
Intel order number G13326-003
132
Progress Code
Diagnostic LED Decoder
O = On, X=Off
Upper Nibble Lower Nibble
MSB 8h 4h 2h 1h 8h 4h 2h 1h LSB
#7 #6 #5 #4 #3 #2 #1 #0
Description
0xB1
O X O O X X X O
RT Set Virtual Address Map End
0xB2
O X O O X X O X
DXE Legacy Option ROM init
0xB3
O X O O X X O O
DXE Reset system
0xB4
O X O O X O X X
DXE USB Hot plug
0xB5
O X O O X O X O
DXE PCI BUS Hot plug
0xB6
O X O O X O O X
DXE NVRAM cleanup
0xB7
O X O O O O O O
DXE Configuration Reset
0x00
X X X X X X X X
INT19
BIOS Recovery
0xF0
O O O O X X X X
PEIM which detected forced Recovery
condition
0xF1
O O O O X X X O
PEIM which detected User Recovery
condition
0xF2
O O O O X X O X
Recovery PEIM (Recovery started)
0xF3
O O O O X X O O
Recovery PEIM (Capsule found)
0xF4
O O O O X O X X
Recovery PEIM (Capsule loaded)

Intel S1200BTS Specifications

General

Chipset	Intel C204 Chipset
Form Factor	MicroATX
Processor Socket	LGA 1155
Number of Processors Supported	1
Number of Memory Slots	4
Processor Support	Intel Xeon E3-1200 series
Memory Support	DDR3 ECC UDIMM
Expansion Slots	1 PCI-E x16 Gen3, 1 PCI-E x4 Gen2, 1 PCI-E x1 Gen2, 1 PCI 32bit/33MHz
Storage	4 x SATA 3Gb/s, 2 x SATA 6Gb/s
Network Interface	Dual Gigabit Ethernet ports
Memory Speed	1333 MHz
RAID Supported	RAID 0, 1, 5, 10
USB Ports	4 rear
