Intel® Xeon™ Processor with 800 MHz System Bus
60 Datasheet
F2 VSS Power/Other G24 VCC Power/Other
F3 VID0 Power/Other Output G25 VSS Power/Other
F4 VCC Power/Other G26 VCC Power/Other
F5 BPM3# Common Clk I/O G27 VSS Power/Other
F6 BPM0# Common Clk I/O G28 VCC Power/Other
F7 VSS Power/Other G29 VSS Power/Other
F8 BPM1# Common Clk I/O G30 VCC Power/Other
F9 GTLREF Power/Other Input G31 VSS Power/Other
F10 VTT Power/Other H1 VCC Power/Other
F11 BINIT# Common Clk I/O H2 VSS Power/Other
F12 BR1# Common Clk Input H3 VCC Power/Other
F13 VSS Power/Other H4 VSS Power/Other
F14 ADSTB1# Source Sync I/O H5 VCC Power/Other
F15 A19# Source Sync I/O H6 VSS Power/Other
F16 VCC Power/Other H7 VCC Power/Other
F17 ADSTB0# Source Sync I/O H8 VSS Power/Other
F18 DBSY# Common Clk I/O H9 VCC Power/Other
F19 VSS Power/Other H23 VCC Power/Other
F20 BNR# Common Clk I/O H24 VSS Power/Other
F21 RS2# Common Clk Input H25 VCC Power/Other
F22 VCC Power/Other H26 VSS Power/Other
F23 GTLREF Power/Other Input H27 VCC Power/Other
F24 TRST# TAP Input H28 VSS Power/Other
F25 VSS Power/Other H29 VCC Power/Other
F26 THERMTRIP# Async GTL+ Output H30 VSS Power/Other
F27 A20M# Async GTL+ Input H31 VCC Power/Other
F28 VSS Power/Other J1 VSS Power/Other
F29 VCC Power/Other J2 VCC Power/Other
F30 VSS Power/Other J3 VSS Power/Other
F31 VCC Power/Other J4 VCC Power/Other
G1 VSS Power/Other J5 VSS Power/Other
G2 VCC Power/Other J6 VCC Power/Other
G3 VSS Power/Other J7 VSS Power/Other
G4 VCC Power/Other J8 VCC Power/Other
G5 VSS Power/Other J9 VSS Power/Other
G6 VCC Power/Other J23 VSS Power/Other
G7 BOOT_SELECT Power/Other Input J24 VCC Power/Other
G8 VCC Power/Other J25 VSS Power/Other
G9 VSS Power/Other J26 VCC Power/Other
G23 LINT1/NMI Async GTL+ Input J27 VSS Power/Other
Table 22. Pin Listing by Pin Number (Sheet 3 of 8)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
Pin
No.
Pin Name
Signal
Buffer Type
Direction
