Intellian v240M - Three Packages Composition

19
PLANNING INSTALLATION
Three Packages Composition
Radome Package
Radome package consists of the following items:
• Upper and lower Radome panels
• A cap and a side hatch
• A Ku module box and a Ku module support pipe
Figure 4. Radome Package Dimension
Figure 5. Ku Module Box and Ku Module Support Pipe
H
W
D
NOTE: Size: 3015mm x 2265mm x 2225mm (W x D x H)
