21
PLANNING INSTALLATION
Frame Package
The Frame package consists of the following items:
• Base frame and air-conditioner frame
• Post
• Air-conditioner (optional)
Figure 8. Frame Package Dimension
Figure 9. Preassembled Radome Base Frame
The Radome base frame is assembled before it is put into the frame package.
NOTE:
Size: 2515mm x 2265mm x 2225mm (W x D x H)
H
W
D
To Next Page
