61
ACU INSTALLATION
Wi-Fi and Bluetooth Connection
You can connect to the ACU via Wi-Fi and to the antenna via Bluetooth for easy
management and control whenever you are on the vessel. For Bluetooth connec-
tion, see Appendix A: Setup Bluetooth Connection.
Set Up Wi-Fi Connection
Enabling Wi-Fi functionality on the ACU
Setting up a PC (AP Mode) to access the ACU via Wi-Fi
Aptus Web Conrmation
Set Up the ACU to access Wi-Fi
Turn on the Wi-Fi power switch located on the back of the ACU. After 30 seconds,
conrm that a red light appears on the switch.
Set Up the PC to access the ACU via Wi-Fi
Setting up my computer’s wireless IP address:
Control Panel > Network and Sharing Center > Change Adapter Settings >
Right click on the “Local Area Connection” > Click “Properties”
After selecting TCP/ IPv4, click on the properties menu, then select “Obtain an
IP address automatically” as shown in the gure 81.
Wi-Fi On/Off
Switch
Figure 75. Wi-Fi Connection
