See the following chapters for related information and important details:
u
Chapter 5, “System Board,” for details on SCSI connector locations and pinouts.
u
Chapter 6, “Peripherals,” for details on drive locations, jumpers, and cables.
u
Chapter 7, “Power Supply and Cooling Fans,” for details on power supply cable
connectors and pinouts.
Remember the following when installing devices in the system’s drive bays:
u
If you are installing a SCSI drive, have the vendor’s documentation available to follow
instructions for setting the SCSI ID, enabling or disabling termination, installing device
drivers when required, and configuring other drive attributes.
u
If you are installing a drive that connects to an adapter card (such as an EIDE drive), see
the vendor’s documentation for installing the adapter card and required cables. See the
“Adding Expansion Cards” section above for details.
Device Locations
You can add optional mass storage devices to the internal and external drive bays. The
following table provides the drive locations and related information.
Location
Drive Peripheral Bay Max Bay Capacity
1 System disk drive Internal 3.5-inch x 1.6-inch
2 Add-on disk drive Internal 3.5-inch x 1.6-inch
3 Add-on disk drive Internal 3.5-inch x 1.6-inch
4 Add-on device External 5.25-inch x 1.6-inch
5 Add-on device External 5.25-inch x 1.6-inch
6 Floppy disk drive External 3.5-inch x 1.0-inch
7 EIDE CD-ROM External 5.25-inch x 1.6-inch
The following figure shows drive locations with devices installed in all locations. The EIDE
CD-ROM, floppy drive, and system drive are standard. Other devices are available as
options.
NOTE If you are installing an additional EIDE device, you must mount the device in location 4.
