Hardware Overview
The following figure shows the major parts and assemblies inside the server.
Floppy Disk
Drive
CD-ROM Drive
Disk Drives
System Board
Power Supply
with Fan
Chassis
Fan
Disk Drives
(
5.25 inch
)
