Intergraph TDZ 2000 GL2 - System Board; System Configuration Summary

44
System Board
The following table lists the main chip components on the system board.
Component
Description
Form Factor ATX
System BIOS
Phoenix BIOS
Processor(s) Intel Pentium II; 266, 300, 333, 350, or 400 MHz, all SEC
(Single Edge Connector)
Chipset Intel 440 BX series
Combo Controller National PC87309 Super I/O
PCI-to-ISA Bridge Intel 82371EB PCI/ISA/IDE Xcelerator (PIIX4E)
EIDE Controller Intel 82371EB
Universal Serial Bus Ports Intel 82371EB
Video Display Controller Intel 82443BX PCI/AGP
System Configuration Summary
The following table summarizes the main features of the system.
Feature
Description
Processors One or two 266, 300, 333, 350, or 400 MHz Intel Pentium II with
external 512 KB cache
Bus Speed 100 MHz for 350 and 400 MHz processors
66 MHz for 266, 300, and 333 MHz processors
Memory Four banks, one DIMM per bank
Memory Style 168 pin SDRAM DIMM, 10 ns, 3.3V, unbuffered, 64 bit (non-
ECC)
168 pin SDRAM DIMM, 10 ns, 3.3V, unbuffered, 72 bit (ECC)
Memory Type SDRAM (Synchronous Dynamic Random Access Memory)
Memory Speed 100 MHz
Minimum/Maximum
memory
32 MB/1 GB
Memory Expansion 32, 64, 128, or 256 MB increments
Networking 3COM 3C900 10 Mbit PCI combination NIC (optional)
3COM 3C905 10/100 Mbit PCI combination NIC (optional)
OLICOM PCI Token Ring NIC (optional)
