Chapter 1 — Replacing Parts
2 CV30 Fixed Mount Computer Service Manual
Cautions
Replacing Parts
Use this section to understand how to replace the spared parts on the
CV30. Each procedure lists the tools and parts you need to complete
replacing the part.
Opening the Top Cover (Radome)
To open the top cover, you need these parts and tools.
Note: Opening this product can result in voiding the warranty. The
internal workings of this product can only be accessed by Intermec service
personnel.
Integrated circuits on the printed circuit board (PCB) in the computer
are very sensitive to damage by electrostatic discharge (ESD). Prevent
ESD by always wearing skin contact ground straps firmly attached to
the equipment metal base assembly when working inside of the
computer. Never open the computer without safeguarding the entire
work area with ESD protection. Failure to comply may result in
damage to PCB components.
Vorsicht: Integrierte Schaltungen auf der Leiterplatte (LP) im
Computer sind äußerst empfindlich auf Schäden durch elektrostatische
Entladung (ESD). Zur Verhinderung von elektrostatischer Entladung
bei Arbeiten im Computer immer Ableitungsschlaufen mit
Hautkontakt tragen, die fest am Metallsockel der Ausrüstung befestigt
sind. Den Computer nie öffnen, bevor der gesamte Arbeitsbereich mit
Schutzvorrichtungen gegen elektrostatische Entladung gesichert ist.
Andernfalls könnten die LP-Komponenten beschädigt werden.
This icon appears at the beginning of any procedure in this manual that
could cause you to touch components (such as printed circuit boards)
that are susceptible to damage from electrostatic discharge (ESD).
When you see this icon, you must follow standard ESD guidelines to
avoid damaging the equipment you are servicing.
Parts and Tools
Description Part Number
Small Phillips screwdriver
Antenna cable remover 591802-001
To Next Page
