Intermec EasyCoder F2 – Installation & Operation Ed. 2 17
Chapter 3 Installation
Front View
On the front of the printer are the display window, the control lamps
and the keyboard. These features allow the operator to control
and set up the printer manually, in addition to the remote control
facilities offered by the Intermec Fingerprint fi rmware and the
Intermec Shell startup program.
The printed labels, tickets or tags are fed out through the front
of the print unit
Side Door
Control Lamps
Display
Keyboard
Print Key
Print Mechanism
