Intermec EasyCoder F2 – Installation & Operation Ed. 2 23
Chapter 3 Installation
Connections
Power
Computer
1 Place the printer on a level surface, near a mains electrical
outlet and with easy access for loading paper and for removing
printout.
2 Check that the printer is switched off.
3 Connect the power cable to the mains receptacle on the rear plate
and to the electrical outlet.
The Easycoder F2 is fi tted with one DB25 female connector for
the RS 232 serial interface port and one class B connector for the
USB port (see Appendix 3).
• RS 232 Serial Interface
Use the serial interface with Direct Protocol or Intermec
Fingerprint programming because you can receive error messages
from your printer. Before you can use the serial interface,
you may need to set up the communication parameters, such
as baudrate, parity etc. as described in chapter 6 “Setting
Up the Printer”.
• USB Interface
The USB interface is intended for future applications.
• Optional Interface Board
Refer to Appendix 3 and the separate documentation delivered
with the boards for connection and setup instructions.
Switch off both the PC and the printer before connecting them
together.
