Intermec EasyCoder F2 – Installation & Operation Ed. 272
Chapter 9 Options
The EasyCoder F2 comes with either a short side door, that only
covers the print unit, or with a long side door, that encloses the entire
paper compartment. The long side door has a slot for external paper
supply. The long side door is generally illustrated throughout this
manual, but pictures of the short side door can be found at the start of
this chapter and in chapter 5 “Paper Load/Quick-Load”.
The rewind unit is an optional device for peel-off operation, i.e. the
labels are separated from a backing paper (liner) after printing and
the backing paper is wound up on an internal spool. The rewind kit
also includes a guide shaft.
Peel-off cannot be combined with quick-load guides, see below.
The rotating paper supply spool is designed to fi t paper roll cores with
an internal diameter of 38 – 40 mm (1.5"). The spool can be fi tted in
the same positions as the paper hanger (see chapter 3 “Installation”).
Being factory installed, the position of the paper supply spool is not
intended to be changed by the operator.
The 3 inch/76 mm adapter is used in connection with a rotating
paper supply spool and makes it possible to use paper rolls with 3
inch/76 mm inner diameter paper cores. The 3" adapter cannot be
used in connection with a paper hanger.
The adapter is pressed onto the paper supply spool and held in
place by a screw.
For Quick-Load operation (see chapter 5 “Paper Load”), a set of
paper guides is fi tted at the rear of the print unit instead of the
standard guide ring. The outer guide is adjustable for different
paper widths. The quick-load guides are included as standard in
the delivery (either factory-fi tted or loose). They can easily be
fi tted by the operator:
1. Open the upper paper guide (see illustration in chapter 12
“Maintenance/Cleaning the Paper Guides”).
2. Pull out the standard guide ring from the shaft.
3. Fit the quick-load guides onto the shaft as illustrated on the
fi rst page of this chapter.
Side Doors
Rewind Unit
3" Adapter
Paper Supply
Spool
Quick-Load
Guides
