Intermec EasyCoder F2 – Installation & Operation Ed. 222
Chapter 3 Installation
Print Mechanism
The print mechanism features a high-performance 8 dots/mm
(≈200 dpi) thermal printhead with quick-mount fi ttings to facilitate
replacement.
Thermal Printhead
Tear Off Edge
Pressure Arm
Printhead Lift Knob
Label Stop Sensor
Position Adjustment
(bottom sensor hidden)
Paper Guide
Locking Nut
Platen Roller
