Intermec SR30 User Manual

Chapter 3 — Troubleshooting and Maintaining the SR30
SR30 Handheld Scanner User’s Guide 23
8 Double-click Co-processor upgrade (HIP). The firmware
upgrade bar code is added to the setup sheet.
9 Scan the firmware upgrade bar code on screen, or print the
bar code set up sheet and scan the bar code.
10 From the Tools menu, select Upgrade product firmware.
The next screen appears.
11 Select the component you want to upgrade and click Next.
The Firmware selection window appears.
12 Click Browse to browse to the location of the HIP firmware
upgrade file, select the file, and click Open.
Note: After you scan the firmware upgrade bar code, you
have 1 minute to start the upgrade process.

Intermec SR30 Specifications

General

Type	Handheld bar code reader
Scanner type	-
Optical sensor resolution	- pixels
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, Code 93, EAN 2, EAN 5, EAN-13, EAN-8, MSI, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Data Matrix
Input voltage	5 V
Power source type	USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	Blue, Grey
International Protection (IP) code	IP30

Weight and Dimensions

Width	72.5 mm
Weight	190 g
