International Electronics prox.pad plus - Figure 2-2 Identifying Pin Connectors

P5
NOTE: P3 Not Used
1-Blue (Terminator)
2-Brown (Data A)
3-White (Data B)
4-Green (Data GND)
S
ystem Power: 12VDC
Connections for remote
installation of proximity
antenna
F
or RS-485
C
ommunications
1
-Gray (Main Relay N/C)
2
-Green (Main Relay N/C)
3
-Blue (Main Relay C)
4
-Black (-V)
5
-Red (+V
1-Green (Aux Relay N/O
)
2-Gray (Aux Relay N/C
)
3-Blue (Aux Relay C)
4-Brown (REX Loop)
5-Orange (Door Loop)
6-White (Loop Commo
n)
1-Red (Bi Color LED)
2-Black (Bi Color LED)
3-White (Antenna +)
4-White (Antenna -)
)
Figure 2-2 Identifying Pin Connectors
