International Electronics prox.pad plus - Figure 3-10 Networking Multiple Prox.pad Plus Units Together

Device #1
Device #2
Door #1
Door #2
NOTE: The maximum
number of devices on a
single network is 32.
RS-232 to RS-485
Converter or IEI
Gateway
2-White (Data A)
3-Brown (Data B)
4-Blue (Data GND)
P5
P1
P3
P2
P1
P3
P2
P5
P4
P4
Figure 3-10 Networking Multiple prox.pad plus
Units Together
3.3 Networking Multiple prox.pad plus Units Together Chapter 3: Wiring
prox.pad plus Install/Program. Manual, PPP, D2 3-15
