International Electronics prox.pad plus - Figure 3-1 Wiring the Aux Relay for Alarm Shunt Operation

P5
TO ALARM PANEL
D
OOR
C
ONTACT
G
OING BACK
T
O ALARM
P
ANEL
TO ALARM PANEL
GREEN
(N/O)
BLUE ( C )
ORANGE
WHITE
SEPARATE DOO
R
CONTACT BEING
MONITORED BY
THE prox.pad un
it
Figure 3-1 Wiring the Aux Relay
for Alarm Shunt Operation
Chapter 3: Wiring 3.1 Wiring the prox.pad plus Unit
3-2 prox.pad plus Install/Program. Manual, PPP, D2
