Table 4-2. prox.pad plus LED Indicators/Sounder Operations
LED or Sounder Visual/Audible
Condition
Description
Yellow LED Slow blink Unit is in Program mode
Rapid blink Verify mode is active (checking that the
last two values in sequence match)
Steady Program error; to clear, press * or error
lockout
Very rapid blink Memory (eeprom) erase is in progress
(commands 40/46, loop-back)
Bi-color LED Steady red Lock output deenergized
Steady green Lock output is energized (timed or
latched)
Red/green
alternating
Awaiting second PIN during “Card AND
Code” access attempt
Green blink Auto-unlock active
Sounder Short beep
(100 ms) every 2
seconds
Audio alert #2 is active
Sounder 1/2 sec
on, 1/2 sec off
Audio alert #1 is active
Double beep Lockout is canceled
Pair of double
beeps
Lockout is activated
3 slow beeps
(250 ms), then
single beep
Self-test is complete
Chapter 4: Programming 4.1 Programming Overview
4-4 prox.pad plus Install/Program. Manual, PPP, D2
