This feature is useful considering the product only has
two relays; you can assign these relays to any of these
functions. There are only a few things to keep in mind
when assigning the outputs.
• Any virtual output can be assigned to any physical
output.
• A virtual output can be assigned to multiple physi-
cal outputs.
• A physical output can only have one virtual output
assigned to it.
To assign the outputs, use the following command:
10 # virtual output # physical output # **
The chart below shows the output options with the
corresponding value.
Virtual Outputs Physical Outputs
1=Lock 1=MainRelay
2=AlarmShunt 2=AuxRelay
3 = P ropped Door 5 = Audio Alert #1
4=ForcedDoor 6=AudioAlert#2
For example, to assign the Forced Door Output to the
Aux Relay, enter the following comm and in Program
mode:
10#4#2#**
After entering this command, the Forced Door Output
is still assigned to Audio Alert #1. If you do not want
the audio alert to sound for Forced Door, you MUST
disable Audio Alert #1. To disable an output, enter a
0 for the virtual output. To disable Audio Alert #1 enter
following command:
10#0#5#**
NOTE: The audio alerts use the local keypad
sounder. Audio Alert #1 is indicated by a ½ second
on, ½ second off beeping. Audio Alert #2 is indi-
cated by a short beep every two seconds.
4.3 Programming Outputs Chapter 4: Programming
prox.pad plus Install/Program. Manual, PPP, D2 4-17
