Product group: Brakes
Product family: Spring-applied brake
Type: 458
Size: 06, 08, 10, 12, 14, 16, 18, 20, 25
Design/type:
E - adjustable (brake torque can be reduced via torque adjustment ring)
N - not adjustable
L – not adjustable, long-life design
INTORQ B FK
Not coded: Connection voltage, hub bore hole, options
Checking the delivery
After receipt of the delivery, check immediately whether the items delivered match the accompanying pa-
pers.
INTORQ does not accept any liability for deficiencies claimed subsequently.
¾
Claim visible transport damage immediately to the deliverer.
¾
Claim visible deficiencies or incomplete deliveries immediately to INTORQ GmbH & Co. KG.
NOTICE
Labelling of drive systems and individual components
¾
Drive systems and components are unambiguously designated by the labelling on their
name plates.
¾
The spring-applied INTORQ brake is also delivered in single modules which can then be
put together by the customer according to their requirements. The specifications – particu-
larly the packaging label, name plate and type code – apply to a complete stator.
¾
The labelling is not included when components are delivered individually.
INTORQ | BA 14.0168 | 11/2018 5
