Assembly
4Assembly
4.1SafeAssembly
WARNING!
RiskofInjury
Improperassemblymaycauseinjuryordamage.
–UseonlyInvacarepartsintheassemblyofthispatient
lift.Thebaselegs,themast,boom,pumpassembly
andthehangerbararemanufacturedtospecifications
thatassurecorrectalignmentofallpartsforsafe
functionaloperation.
–DONOTovertightenthemountinghardware.This
willdamagethemountingbracket.
4.2AssemblingtheMasttotheBase
1.LockrearcastersA(DetailA).
2.RemovetheshoulderboltB,nutCandwashersD,fromthe
mastE.
3.Raisethemastassemblytoanuprightpositionuntilitlocksin
place(DetailB).
4.Installtheshoulderboltandwashers,throughthemastandthe
baseF.
5.Securewiththenut.
WARNING!
–Themastmaybefoldedforstorageortransporting.
Eachtimethemastisfolded,themastMUSTbe
properlysecuredtothebaseassembly.
1171892-A13
