Invacare ILIFTEE - Maintaining the Base Adjustment

Maintenance
8.13MaintainingtheBaseAdjustment
ThebaseAadjustmentshouldnotrequireanyattentionotherthan
adjustingthelinkagerods.
CAUTION!
Damagetotheliftmayoccur.
–Thelegactuatormustbeinthefullyclosedposition
beforeadjustingthelinkagerods.
1.Closethelegsalltheway.RefertoClosing/OpeningManual
Legs,page19orClosing/OpeningElectricLegs,page20.
2.CheckthesquarenessofthelegsBwhenintheclosedposition.
3.PlaceasquareContheinsideofthelegsandbasetodetermine
the90°alignmentD.
4.AdjustthelinkagerodsEuntil90°alignmentisachieved.
CAUTION!
Damagetotheliftmayoccur.
–DONOTadjustthelinkagerodssothelegsareatless
than90°alignment.
1171892-A45
