Invacare ILIFTEE - Replacing the Electric Actuator

I-Lift™
8.9ReplacingtheElectricActuator 1.RemovethecapsA,nutB,washersC,bushingDandshoulder
boltEthatsecuretheactuatorFtotheboommounting
bracketG.
2.ResttheboomHonyourshoulderandremovethecapsI,nut
J,boltK,washersLandbushingMfromthemastmounting
bracketN.
3.Removetheelectricactuator.
4.ReverseSTEPS1-3forinstallation.
CAUTION!
RiskofDamage
Improperassemblymaycauseinjuryordamage.
–DONOTovertightenthemountinghardware.This
willdamagethemountingbracket.
Besurethattheboltorpiniscompletelythroughthe
holesoftheboomassemblymountingbracketandthe
actuatorassembly.Theboomassemblywillpivoteasilyif
themountinghardwareisalignedproperlywhentheboom
assemblyissecuredtothemast.
42
1171892-A
