Invacare ILIFTEE - Replacing the Leg Actuator

Maintenance
8.10ReplacingtheLegActuator 1.RemovethewirelockAthatsecuresthelegactuatorcable
tothemast.
2.DisconnectthelegactuatorcableBfromthebottomofthe
controlboxC.
3.RemovehitchpinsDsecuringthepinEtothelegactuator
FandmastbracketG.
4.Removethepinfromthelegactuatorandmastbracket.
5.Performthefollowingtoremovethelegactuatorfromthepivot
bracketH(DetailA):
WARNING!
RiskofInjury
Injurytopersonnelordamagetothepatientlift
mayoccur.
–Ensurethatthereissufficientroomtoturnthe
patientliftonitssideandthatthefloorareais
clearofdebris.
a.Turnthepatientliftonitsside.
b.RemovethehitchpinIsecuringthepinJtothepivot
bracket.
c.Removethepinfromthelegactuatorandpivotbracket.
d.Returnthepatientlifttotheuprightposition.
6.SlidethelegactuatoroutoftheslotKinthebaseofthepatient
lift(DetailB).
7.ReverseSTEPS1-5toinstallthelegactuator.
Positionlegactuatorintothemastbracketandmovethe
legstoaligntheholesinthelegactuatorwiththeholesin
themastbracket.
1171892-A43
