Invacare ILIFTEE - Checking and Tightening Mast Pivot Bolt; Replacing the Swivel Bar

I-Lift™
8.11CheckingandTighteningMastPivotBolt
1.CheckthattheboltAisthroughthebracketBandthelocknut
Cistightandsecure.
2.Ifneeded,dooneormoreofthefollowing:
•Tightenlocknutandback-offthelocknut1/8ofaturn.
•Replacethelocknut.
8.12ReplacingtheSwivelBar
WARNING!
RiskofInjury
Wornordamagedpartsoftheliftmaycauseinjuryto
thepatientorassistants.
–Afterthefirstyearofuse,thehooksofthehanger
barandmountingbracketsoftheboomshouldbe
inspectedeverysixmonthstodeterminetheextent
ofwear.Ifthesepartsbecomeworn,replacement
mustbemade.
Ifthescaleisinstalledonthelift,referto9.3Installingthe
Scale,page48toreplacethehangerbar.
1.RemovetherubbercoverAfromtheboomB.
2.RemovetheclipCandclevispinDsecuringthehangerbar
pinEtotheboom.
3.ReverseSTEPS1-2toinstallthenewhangerbar.
