Invacare ILIFTEE - Adjusting the Pump Control Valve

Maintenance
8.8AdjustingthePumpControlValve
WARNING!
–Alwaysremovethepatientfromtheliftbefore
performingthisprocedure.DONOTperformthis
adjustmentwhileliftingapatient.Seriousinjurymay
occur.
ThisprocedureappliestotheILIFTHMmodelsonly.
1.TurnthecontrolvalveAsoitwillclearthepumphandleB
whenthehandleisfullyretracted.
2.LoosenthesetscrewCafewturns.
3.Removethecontrolvalvelever.
4.HandtightenthecontrolrodDbyturningitclockwise.
5.Reinstallthecontrolvalvelever.
6.Positiontheleversoitclearsthehandlewhenitisfullyretracted.
7.Tightenthesetscrew.
8.Testthehydraulicpumpwithaload.
