Invacare ILIFTEE - Assembling the Electric Actuator to the Boom

I-Lift™
4.4AssemblingtheElectricActuatortothe
Boom
CAUTION!
RiskofDamage
–DONOTovertightenthemountinghardware.This
willdamagethemountingbracket.
1.RemovethequickreleasepinAfromthemastmountingbracket
B(DetailA).
2.LiftthehookCsecuringthehangerbarDtothemast.
3.RemovethecapsE,boltF,washersG,bushingHandnutI
fromtheboommountingbracketJ(DetailB).
ThebottomoftheelectricactuatorassemblyKwill
alreadybeassembledtothemastmountingbracket
(DetailC).
4.Lift-upontheboomandplaceitonyourleftshoulder.
5.Lettheactuatorrestonyourright-sideofyourchestandrotate
theshaftextensionLoftheactuatorassemblyuntilitlines-up
withthemountingholesintheboomassembly.
6.Aligntheholesoftheboomassemblymountingbracketwith
thoseoftheactuator
Besurethattheboltiscompletelythroughtheholesof
theboommountingbracketandtheactuatorassembly.
Theboomassemblywillpivoteasilyifthemounting
hardwareisalignedproperlywhentheboomissecured
tothemast.
7.Installthebolt,washers,nut,bushingandcaps.
8.Plugintheelectricalconnectors(notshown)fromtheelectric
actuatortothebottomofthebatteryassembly.
9.Plugthependantcontrolintothebottomofthebatteryassembly
M.Besurethependantcontrolplugisfullyinserted.
