4.5InstallingtheLegActuatortotheBase
1.Performthefollowingtosecurethelegactuatortothemast
bracket:
a.PositionlegactuatorAintothemastbracketB.
b.MovethelegsCtoaligntheholesinthelegactuatorwith
theholesinthemastbracket.
c.InstallthepinDthroughtheholesofthelegactuatorand
mastbracketandsecurewithhitchpinsE.
2.ConnectthelegactuatorcableFtothebottomofthecontrol
boxG.
3.Ensuretheactuatorplugisfullypushedintothecontrolbox.
4.Checktheservicelight.Referto4.7CheckingtheServiceLight,
page18.
4.6InstallingtheShifterHandle
ThisprocedureappliestotheILIFTHMandILIFTEMonly.
1.RemovetheshifterhandleAfromthepackagingcarton.
2.Line-uptheshifterhandlethreadsBwiththreadedopeningC
inthebase.
3.Turntheshifterhandleclockwiseandsecurelytightenintothe
base.
