10. Technical Data
10.1. Environmental
Operational ambient temperature range : -20 ... 40°C (frost and condensation free)
Storage ambient temperature range : -40 … 60°C
Maximum altitude : 2000m. Derate above 1000m: 2.5% / 100m
Maximum humidity : 95%, non-condensing
10.2. Rating Tables
Frame
Size
kW HP Input
Current
Fuse / MCB (Type B) Maximum Cable
Size
Output
Current
Recommended
Brake Resistance
Non UL UL mm AWG A 
110 - 115 (+ / - 10%) V 1 Phase Input, 230V 3 Phase Output (Voltage Doubler)
1 0.37 0.5 7. 8 10 10 8 8 2.3 -
1 0.75 1 15. 8 25 20 8 8 4.3 -
2 1.1 1.5 21.9 32 30 8 8 5.8 100
200 - 240 (+ / - 10%) V 1 Phase Input, 3 Phase Output
1 0.37 0.5 3.7 10 6 8 8 2.3 -
1 0.75 1 7. 5 10 10 8 8 4.3 -
1 1.5 2 12 . 9 16 17. 5 8 8 7 -
2 1.5 2 12 . 9 16 17. 5 8 8 7 100
2 2.2 3 19. 2 25 25 8 8 10.5 50
3 4 5 29.2 40 40 8 8 15 . 3 25
200 - 240 (+ / - 10%) V 3 Phase Input, 3 Phase Output
1 0.37 0.5 3.4 6 6 8 8 2.3 -
1 0.75 1 5.6 10 10 8 8 4.3 -
1 1.5 2 9.5 16 15 8 8 7 -
2 1.5 2 8.9 16 15 8 8 7 10 0
2 2.2 3 12 .1 16 17. 5 8 8 10.5 50
3 4 5 20.9 32 30 8 8 18 25
3 5.5 7. 5 26.4 40 35 8 8 24 20
4 7. 5 10 33.3 40 45 16 5 30 15
4 11 15 50.1 63 70 16 5 46 10
380 - 480 (+ / - 10%)V 3 Phase Input, 3 Phase Output
1 0.75 1 3.5 6 6 8 8 2.2 -
1 1.5 2 5.6 10 10 8 8 4.1 -
2 1.5 2 5.6 10 10 8 8 4.1 250
2 2.2 3 7. 5 16 10 8 8 5.8 200
2 4 5 11 . 5 16 15 8 8 9.5 12 0
3 5.5 7. 5 17. 2 25 25 8 8 14 100
3 7. 5 10 21. 2 32 30 8 8 18 80
3 11 15 2 7. 5 40 35 8 8 24 50
4 15 20 34.2 40 45 16 5 30 30
4 18.5 25 44.1 50 60 16 5 39 22
4 22 30 51.9 63 70 16 5 46 22
NOTE Cable sizes shown are the maximum possible that may be connected to the drive. Cables should be selected according to
local wiring codes or regulations at the point of installation.
10.3. Single Phase Operation of Three Phase Drives
All drive models intended for operation from three phase mains power supply (e.g. model codes ODE-3-xxxxxx-3xxx) may be
operated from a single phase supply at up to 50% of maximum rated output current capacity.
In this case, the AC power supply should be connected to L1 (L) and L2 (N) power connection terminals only.
