Invertek Drives OPTIDRIVE E3 User Manual

6 | Optidrive ODE-3 IP66 Outdoor Rated User Guide | Version 1.00
www.invertekdrives.com
2.4. Drive Model Numbers
110 – 115V ± 10% - 1 Phase Input – 3 Phase 230V Output (Voltage Doubler)
Model Number
kW HP
Output Current
(A)
Frame Size
With Filter Without Filter
N/A ODE-3-110023-101# 0.5 2.3 1
N/A ODE-3-110043-101# 1 4.3 1
N/A ODE-3-210058-104# 1.5 5.8 2
200 – 240V ± 10% - 1 Phase Input – 3 Phase Output
Model Number
kW HP
Output Current
(A)
Frame Size
With Filter Without Filter
ODE-3-120023-1F1# ODE-3-120023-101# 0.37 0.5 2.3 1
ODE-3-120043-1F1# ODE-3-120043-101# 0.75 1 4.3 1
ODE-3-120070-1F1# ODE-3-120070-101# 1.5 2 7 1
ODE-3-220070-1F4# ODE-3-220070-104# 1.5 2 7 2
ODE-3-220105-1F4# ODE-3-220105-104# 2.2 3 10.5 2
ODE-3-320153-1F4# ODE-3-320153-104# 4.0 5 15 . 3 3
200 – 240V ± 10% - 3 Phase Input – 3 Phase Output
Model Number
kW HP
Output Current
(A)
Frame Size
With Filter Without Filter
ODE-3-120023-3F1# ODE-3-120023-301# 0.37 0.5 2.3 1
ODE-3-120043-3F1# ODE-3-120043-301# 0.75 1 4.3 1
ODE-3-120070-3F1# ODE-3-120070-301# 1.5 2 7 1
ODE-3-220070-3F4# ODE-3-220070-304# 1.5 2 7 2
ODE-3-220105-3F4# ODE-3-220105-304# 2.2 3 10.5 2
ODE-3-320180-3F4# ODE-3-320180-304# 4.0 5 18 3
ODE-3-320240-3F4# ODE-3-320240-304# 5.5 7. 5 24 3
ODE-3-420300-3F4# ODE-3-420300-304# 7. 5 10 30 4
ODE-3-420460-3F4# ODE-3-420460-304# 11 15 46 4
380 – 480V ± 10% - 3 Phase Input – 3 Phase Output
Model Number
kW HP
Output Current
(A)
Frame Size
With Filter Without Filter
ODE-3-140022-3F1# ODE-3-140022-301# 0. 75 1 2.2 1
ODE-3-140041-3F1# ODE-3-140041-301# 1.5 2 4 .1 1
ODE-3-240041-3F4# ODE-3-240041-304# 1.5 2 4 .1 2
ODE-3-240058-3F4# ODE-3-240058-304# 2.2 3 5.8 2
ODE-3-240095-3F4# ODE-3-240095-304# 4 5 9.5 2
ODE-3-340140-3F4# ODE-3-340140-304# 5.5 7. 5 14 3
ODE-3-340180-3F4# ODE-3-340180-304# 7. 5 10 18 3
ODE-3-340240-3F4# ODE-3-340240-3042 11 15 24 3
ODE-3-440300-3F4# ODE-3-440300-3042 15 20 30 4
ODE-3-440390-3F4# ODE-3-440390-3042 18.5 25 39 4
ODE-3-440460-3F4# ODE-3-440460-3042 22 30 46 4
NOTE
For IP66 Non Switched Units, replace ‘#’ with ‘A’
For IP66 Switched Units, replace ‘#’ with ‘B’
General Information & Ratings
2
