Parameters
6
6. Parameters
6.1. Standard Parameters
The parameter set is arranged in Groups according to the following structure:
Parameter Group Range Access Level Access Type
P00 P00-01 to P00-20 Extended Read Only
P00-21 to P00-50 Advanced Read Only
Basic Parameters P-01 to P-14 Basic Read / Write
Extended Parameters P-15 to P-50 Extended Read / Write
Advanced Parameters P-51 to P-60 Advanced Read / Write
Access to all parameter groups is controlled by setting P-14 as follows:
P-14 = P-37 (Factory setting: 101) Allows Extended Parameter Access
P-14 = P-37 + 100 (Factory Setting: 201) Allows Advanced Parameter Access
In order to prevent possible damage to the drive and connected machinery, certain parameters are locked during operation of the
drive to prevent change. In the case that the drive is enabled, and the user tries to change the parameter, an “L” is shown on the left of
the display.
6.2. Parameter List
6.2.1. Standard Parameters
Par. Function Page No.
P-01 Maximum Frequency / Speed Limit 23
P-02 Minimum Frequency / Speed Limit 23
P-03 Acceleration Ramp Time 23
P-04 Deceleration Ramp Time 23
P-05 Stopping Mode / Mains Loss Response 24
P-06 Energy Optimiser 24
P-07 Motor Rated Voltage / Back EMF at rated speed (PM / BLDC) 22
P-08 Motor Rated Current 22
P-09 Motor Rated Frequency 22
P-10 Motor Rated Speed 22
P-11 Low Frequency Torque Boost 22
P-12 Primary Command Source 24
P-13 Operating Mode Select 24
P-14 Extended Menu Access code 26
6.2.2. Extended Parameters
Par. Function Page No.
P-15 Digital Input Function Select 26
P-16 Analog Input 1 Signal Format 24
P-17 Maximum Effective Switching Frequency 24
P-18 Output Relay Function Select 25
P- Relay Threshold Level 25
P-20 Preset Frequency / Speed 1 26
P-21 Preset Frequency / Speed 2 26
P-22 Preset Frequency / Speed 3 26
P-23 Preset Frequency / Speed 4 26
P-24 2nd Ramp Time (Fast Stop) 23
