6.4. P-00 Read Only Status Parameters
Par.
Description Explanation
P00-01 1st Analog input value (%) 100% = max input voltage.
P00-02 2nd Analog input value (%) 100% = max input voltage.
P00-03 Speed reference input (Hz / RPM) Displayed in Hz if P-10 = 0, otherwise RPM.
P00-04 Digital input status Drive digital input status.
P00-05 User PI output (%) Displays value of the User PI output.
P00-06 DC bus ripple (V) Measured DC bus ripple.
P00-07 Applied motor voltage (V) Value of RMS voltage applied to motor.
P00-08 DC bus voltage (V) Internal DC bus voltage.
P00-09 Heatsink temperature (˚C) Temperature of heatsink in ˚C.
P00-10 Run time since date of manuf. (Hours) Not affected by resetting factory default parameters.
P00-11 Run time since last trip (1) (Hours)
Run-time clock stopped by drive disable (or trip), reset on next enable only if a trip
occurred. Reset also on next enable after a drive power down.
P00-12 Run time since last trip (2) (Hours)
Run-time clock stopped by drive disable (or trip), reset on next enable only if a trip
occurred (under-volts not considered a trip) – not reset by power down / power
up cycling unless a trip occurred prior to power down.
P00-13 Trip Log Displays most recent 4 trips with time stamp.
P00-14 Run time since last disable (Hours) Run-time clock stopped on drive disable, value reset on next enable.
P00-15 DC bus voltage log (V) 8 most recent values prior to trip, 256ms sample time.
P00-16 Heatsink temperature log (˚C) 8 most recent values prior to trip, 30s sample time.
P00-17 Motor current log (A) 8 most recent values prior to trip, 256ms sample time.
P00-18 DC bus ripple log (V) 8 most recent values prior to trip, 22ms sample time.
P00-19 Internal drive temperature log (˚C) 8 most recent values prior to trip, 30 s sample time.
P00-20 Internal drive temperature (˚C) Actual internal ambient temperature in ˚C.
P00-21 CAN process data input Incoming process data (RX PDO1) for CAN: PI1, PI2, PI3, PI4.
P00-22 CAN process data output Outgoing process data (TX PDO1) for CAN: PO1, PO2, PO3, PO4.
P00-23 Accumulated time with heatsink > 85˚C (Hours) Total accumulated hours and minutes of operation above heatsink temp of 85˚C.
P00-24 Accumulated time with drive internal temp >
80˚C (Hours)
Total accumulated hours and minutes of operation with drive internal ambient
above 80˚C.
P00-25 Estimated rotor speed (Hz) In vector control modes, estimated rotor speed in Hz.
P00-26 kWh meter / MWh meter Total number of kWh / MWh consumed by the drive.
P00-27 Total run time of drive fans (Hours)
Time displayed in hh:mm:ss. First value displays time in hrs, press up to display
mm:ss.
P00-28 Software version and checksum Version number and checksum. “1” on LH side indicates I/O processor,
“2“ indicates power stage.
P00-29 Drive type identifier Drive rating, drive type and software version codes.
P00-30 Drive serial number Unique drive serial number.
P00-31 Motor current Id / Iq Displays the magnetising current (Id) and torque current (Iq). Press UP to show Iq.
P00-32 Actual PWM switching frequency (kHz) Actual switching frequency used by drive.
P00-33 Critical fault counter – O-I These parameters log the number of times specific faults or errors occur, and are
useful for diagnostic purposes.
P00-34 Critical fault counter – O-Volts
P00-35 Critical fault counter – U-Volts
P00-36 Critical fault counter – O-temp (h/sink)
P00-37 Critical fault counter – b O-I (chopper)
P00-38 Critical fault counter – O-hEAt (control)
P00-39 Modbus comms error counter
P00-40 CANbus comms error counter
P00-41 I/O processor comms errors
P00-42 Power stage uC comms errors
P00-43 Drive power up time (life time) (Hours) Total lifetime of drive with power applied.
P00-44 Phase U current offset & ref Internal value.
P00-45 Phase V current offset & ref Internal value.
P00-46 Phase W current offset & ref Internal value.
P00-47 Index 1: Fire mode total active time
Index 2: Fire Mode Activation Count
Total activation time of Fire Mode.
Displays the number of times Fire Mode has been activated.
P00-48 Scope channel 1 & 2 Displays signals for scope channels 1 & 2.
P00-49 Scope channel 3 & 4 Displays signals for scope channels 3 & 4.
P00-50 Bootloader and motor control Internal value.
www.invertekdrives.com36 | Optidrive ODE-3 IP66 Outdoor Rated User Guide | Version 2.01
