BPD series PV pumping inverter Function parameters
38
Function
code
Name
Detailed description
Default
Modify
The bigger the value is, the stronger the effect and
faster the adjustment is.
P15.08
KP2
0.00–100.00
The proportion coefficient 2 of the target frequency
The bigger the value is, the stronger the effect and
faster the adjustment is.
15.00
○
P15.09
KI2
0.00–100.00
The integral coefficient 2 of the target frequency
The bigger the value is, the stronger the effect and
faster the adjustment is.
15.00
○
P15.10
PI switching
point
0.0–6553.5V DC
If the absolute value of bus voltage minus the
reference value is bigger than P15.10, it will switch
to P15.08 and P15.09; otherwise it is P15.06 and
P15.07.
20.0V
◎
P15.11
Water-level
control
0: Digital input of the water-level control
If the function code is 0, the water-level signal is
controlled by the digital input. See 45 and 46
functions of S terminal for detailed information. If
the full-water signal is valid, the system will report
the warning (A-tF) and sleep after the time of
P15.13. During the warning, the full-water signal is
invalid and the system will clear the warning after
the time of P15.14. If the empty-water signal is
valid, the system will report the warning (A-tL) and
sleep after the time of P15.32. During the warning,
the empty -water signal is invalid and the system
will clear the warning after the time of P15.33.(the
function codes of P15.13, P15.14, P15.32, P15.33
are related to the water-level control)
1–3: Reserved
0
◎
